You will learn
to develope technical and digital competences,
to develope learning skills,
to check knowledge with physics,
to communicate in English.
RrfAeOL6XmKDj 1 nagranie abstraktu
nagranie abstraktu
Before the test get acquainted with time management during the test:
Eliminating wrong answers.
Substituting data - a reversed method of finding solution.
Estimating data.
Finding the solution and indicating the correct answer.
Ania’s autumn walk with Brutus the dog.
Read the text below and solve tasks 1 - 3.
During her walk with Brutus Anne noticed two gardeners pushing a 100 kg cart up the hill. The height of the hill is 3 m, and the length of the slope is twice as large. The resistance of the cart is 20% of its weight. During the action the cart moves at the speed of 0.5 m s .
R1L9hTtCeuVgJ Exercise 1
Wersja alternatywna ćwiczenia: The minimal work that the workers will do when pushing a cart up the hill is Możliwe odpowiedzi: 1. 4200 J, 2. 2200 J, 3. 4000 J, 4. 5400 J
Wersja alternatywna ćwiczenia: The minimal work that the workers will do when pushing a cart up the hill is Możliwe odpowiedzi: 1. 4200 J, 2. 2200 J, 3. 4000 J, 4. 5400 J
The minimal work that the workers will do when pushing a cart up the hill is
4200 J
2200 J
4000 J
5400 J
RV6BMDxh57UA3 Exercise 2
Wersja alternatywna ćwiczenia: The gardeners pushing the cart uphill worked with power Możliwe odpowiedzi: 1. 350 W, 2. 200 W, 3. 250 W, 4. 300 W
Wersja alternatywna ćwiczenia: The gardeners pushing the cart uphill worked with power Możliwe odpowiedzi: 1. 350 W, 2. 200 W, 3. 250 W, 4. 300 W
The gardeners pushing the cart uphill worked with power
R1a8Qg8evAspI Exercise 3
Wersja alternatywna ćwiczenia: When the cart was stopped on the top of the hill, the rope broke suddenly and the cart began to slide down the hill. The speed of the cart at the base of the hill has a value of Możliwe odpowiedzi: 1. 6 m s , 2. 4 m s , 3. 5 m s , 4. 7 m s
Wersja alternatywna ćwiczenia: When the cart was stopped on the top of the hill, the rope broke suddenly and the cart began to slide down the hill. The speed of the cart at the base of the hill has a value of Możliwe odpowiedzi: 1. 6 m s , 2. 4 m s , 3. 5 m s , 4. 7 m s
When the cart was stopped on the top of the hill, the rope broke suddenly and the cart began to slide down the hill. The speed of the cart at the base of the hill has a value of
Read the text below and solve tasks 4 - 6.
During her walk around the playground, Ania noticed that someone hang a small but heavy stone on a string that was 1 m long. Ania realised that it could be treated as a mathematical pendulum. And its vibration period is given with the formula T = 2 π l g .
RkCJ8LkxDDGaT Exercise 4
Wersja alternatywna ćwiczenia: Within 1 minute such a pendulum will do (choose the answer below) of full swings Możliwe odpowiedzi: 1. 30, 2. 60, 3. 90, 4. 120
Wersja alternatywna ćwiczenia: Within 1 minute such a pendulum will do (choose the answer below) of full swings Możliwe odpowiedzi: 1. 30, 2. 60, 3. 90, 4. 120
Within 1 minute such a pendulum will do (choose the answer below) of full swings
R81xtLXfpydZc Exercise 5
Wersja alternatywna ćwiczenia: For such a pendulum to be a second pendulum (T = 1 s), requires shortening by Możliwe odpowiedzi: 1. 75 cm, 2. 25 cm, 3. 50 cm, 4. 100 cm
Wersja alternatywna ćwiczenia: For such a pendulum to be a second pendulum (T = 1 s), requires shortening by Możliwe odpowiedzi: 1. 75 cm, 2. 25 cm, 3. 50 cm, 4. 100 cm
For such a pendulum to be a second pendulum (T = 1 s), requires shortening by
Rhe104G2debao Exercise 6
Wersja alternatywna ćwiczenia: If you substitute the stone with a new one, with a 4 times bigger mass, then the period of pendulum oscillation would increase Możliwe odpowiedzi: 1. 1 time, 2. 2 times, 3. 4 times, 4. 16 times
Wersja alternatywna ćwiczenia: If you substitute the stone with a new one, with a 4 times bigger mass, then the period of pendulum oscillation would increase Możliwe odpowiedzi: 1. 1 time, 2. 2 times, 3. 4 times, 4. 16 times
If you substitute the stone with a new one, with a 4 times bigger mass, then the period of pendulum oscillation would increase
1 time
2 times
4 times
16 times
Read the text below and solve tasks 7 - 9.
Ania, standing at a distance from the rhythmically marching troop of soldiers, heard a rhythmic, once a second noise of shoes hitting the ground. The speed of sound propagation in the air is 340 m s .
RWU4uJJ8yl7Dq Exercise 7
Wersja alternatywna ćwiczenia: The rhythmical impact of shoes on the ground produces an acoustic wave of length of Możliwe odpowiedzi: 1. 340 m, 2. 170 m, 3. 510 m, 4. 680 m
Wersja alternatywna ćwiczenia: The rhythmical impact of shoes on the ground produces an acoustic wave of length of Możliwe odpowiedzi: 1. 340 m, 2. 170 m, 3. 510 m, 4. 680 m
The rhythmical impact of shoes on the ground produces an acoustic wave of length of
RHErTmpO40pDf Exercise 8
Wersja alternatywna ćwiczenia: Ania knows that the fish swimming in the pond hear the rhythmic strikes of soldiers on the ground very well. But in the water the sound propagates at 1200 m s . So the sound for fish has a frequency of Możliwe odpowiedzi: 1. 1 Hz, 2. 2 Hz, 3. 3 Hz, 4. 4Hz
Wersja alternatywna ćwiczenia: Ania knows that the fish swimming in the pond hear the rhythmic strikes of soldiers on the ground very well. But in the water the sound propagates at 1200 m s . So the sound for fish has a frequency of Możliwe odpowiedzi: 1. 1 Hz, 2. 2 Hz, 3. 3 Hz, 4. 4Hz
Ania knows that the fish swimming in the pond hear the rhythmic strikes of soldiers on the ground very well. But in the water the sound propagates at 1200 m s . So the sound for fish has a frequency of
RWX3x6zjO8pVe Exercise 9
Wersja alternatywna ćwiczenia: Ania carefully watched the march of the unit and found that the sound of the blow was heard when the soldiers had legs raised high. The distance of the troop from Ania was Możliwe odpowiedzi: 1. 170 m, 2. 340 m, 3. 510 m, 4. 680 m
Wersja alternatywna ćwiczenia: Ania carefully watched the march of the unit and found that the sound of the blow was heard when the soldiers had legs raised high. The distance of the troop from Ania was Możliwe odpowiedzi: 1. 170 m, 2. 340 m, 3. 510 m, 4. 680 m
Ania carefully watched the march of the unit and found that the sound of the blow was heard when the soldiers had legs raised high. The distance of the troop from Ania was
Read the text below and solve tasks 10 - 12.
In the park, where Ania was walking with her dog Brutus, someone organised a festiwal, at the end of which, balloons filled with helium were used. They rose vertically upwards at the speed of 3 m s . But on that day, there was a fairly strong wind was blowing at the speed of 4 m s .
R10B9IqMREFeJ Exercise 10
Wersja alternatywna ćwiczenia: When the balloon rose to the height of 90 m, at the same time it travelled the distance of Możliwe odpowiedzi: 1. 150 m, 2. 90 m, 3. 120 m, 4. 210 m
Wersja alternatywna ćwiczenia: When the balloon rose to the height of 90 m, at the same time it travelled the distance of Możliwe odpowiedzi: 1. 150 m, 2. 90 m, 3. 120 m, 4. 210 m
When the balloon rose to the height of 90 m, at the same time it travelled the distance of
R1FPxomqqAvZW Exercise 11
Wersja alternatywna ćwiczenia: With the reference to the speed of Earth the balloon moved at Możliwe odpowiedzi: 1. 5 m s , 2. 3 m s , 3. 4 m s , 4. 7 m s
Wersja alternatywna ćwiczenia: With the reference to the speed of Earth the balloon moved at Możliwe odpowiedzi: 1. 5 m s , 2. 3 m s , 3. 4 m s , 4. 7 m s
With the reference to the speed of Earth the balloon moved at
R1XzIwOfq8ndp Exercise 12
Wersja alternatywna ćwiczenia: If the speed of wind was 2 m s , then the balloon would rise at the speed of Możliwe odpowiedzi: 1. 3 m s , 2. 4 m s , 3. 5 m s , 4. 7 m s
Wersja alternatywna ćwiczenia: If the speed of wind was 2 m s , then the balloon would rise at the speed of Możliwe odpowiedzi: 1. 3 m s , 2. 4 m s , 3. 5 m s , 4. 7 m s
If the speed of wind was 2 m s , then the balloon would rise at the speed of
Read the text below and solve tasks 13 - 15.
It was getting darker and darker and suddenly the 40 lanterns in the park were switched on. Each lamp was fitted with a bulb of the power 460 W, adjusted to the voltage of 230 V.
RXW7yfQekk9xv Exercise 13
Wersja alternatywna ćwiczenia: To lit the park up from the city needs the current Możliwe odpowiedzi: 1. 80 A, 2. 40 A, 3. 60 A, 4. 100 A
Wersja alternatywna ćwiczenia: To lit the park up from the city needs the current Możliwe odpowiedzi: 1. 80 A, 2. 40 A, 3. 60 A, 4. 100 A
To lit the park up from the city needs the current
R1d8bKzg8VpJp Exercise 14
Wersja alternatywna ćwiczenia: If 1 kWh of energy costs 40 gr, we will pay (choose the answer below) for the about 8‑hour‑long operation of the lamps in park Możliwe odpowiedzi: 1. 59 PLN, 2. 24 PLN, 3. 48 PLN, 4. 12 PLN
Wersja alternatywna ćwiczenia: If 1 kWh of energy costs 40 gr, we will pay (choose the answer below) for the about 8‑hour‑long operation of the lamps in park Możliwe odpowiedzi: 1. 59 PLN, 2. 24 PLN, 3. 48 PLN, 4. 12 PLN
If 1 kWh of energy costs 40 gr, we will pay (choose the answer below) for the about 8‑hour‑long operation of the lamps in park
59 PLN
24 PLN
48 PLN
12 PLN
RHxDR2Z5Rk1fK Exercise 15
Wersja alternatywna ćwiczenia: If (due to a failure) the voltage supply dropped to 115 V, then the electrical installation would need the power of Możliwe odpowiedzi: 1. 4.6 kW, 2. 9.2 kW, 3. 23 kW, 4. 46 kW
Wersja alternatywna ćwiczenia: If (due to a failure) the voltage supply dropped to 115 V, then the electrical installation would need the power of Możliwe odpowiedzi: 1. 4.6 kW, 2. 9.2 kW, 3. 23 kW, 4. 46 kW
If (due to a failure) the voltage supply dropped to 115 V, then the electrical installation would need the power of
4.6 kW
9.2 kW
23 kW
46 kW
Rvmy36nE1s5Wj
Analyse your correct and incorrect answers to the Exercises.
R1PPVrUOCdLjw Exercise 16
Przypomnij sobie tytuł abstraktu, wysłuchaj nagrania i spróbuj zaproponować własny temat dla dzisiejszej lekcji.
Przypomnij sobie tytuł abstraktu, wysłuchaj nagrania i spróbuj zaproponować własny temat dla dzisiejszej lekcji.
You did your job well, so now have fun!
Language Exercises RxmX5xpNv0C9Q Exercise 17
Wersja alternatywna ćwiczenia: Indicate which pairs of expressions or words are translated correctly. Możliwe odpowiedzi: 1. acoustic wave - fala akustyczna , 2. wahadło matematyczne - mathematical pendulum , 3. prędkość rozchodzenia się dźwięku - speed of sound propagation , 4. okres drgań - vibration period , 5. moc - frequency , 6. częstotliwość - voltage
Wersja alternatywna ćwiczenia: Indicate which pairs of expressions or words are translated correctly. Możliwe odpowiedzi: 1. acoustic wave - fala akustyczna , 2. wahadło matematyczne - mathematical pendulum , 3. prędkość rozchodzenia się dźwięku - speed of sound propagation , 4. okres drgań - vibration period , 5. moc - frequency , 6. częstotliwość - voltage
Indicate which pairs of expressions or words are translated correctly.
acoustic wave - fala akustyczna
wahadło matematyczne - mathematical pendulum
prędkość rozchodzenia się dźwięku - speed of sound propagation
okres drgań - vibration period
moc - frequency
częstotliwość - voltage
zadanie
Source: GroMar, licencja: CC BY 3.0.
RU9MVsbPpvtTc 1 Interaktywna gra, polegająca na łączeniu wyrazów w pary w ciągu jednej minuty. Czas zaczyna upływać wraz z rozpoczęciem gry. Jeden ruch to odkrywanie najpierw jednej potem drugiej karty z wyrazem. Każdy wyraz jest odczytywany. Kolejny ruch to odkrywanie trzeciej i czwartej karty. W ten sposób odsłuchasz wszystkie wyrazy. Nawigacja z poziomu klawiatury za pomocą strzałek, odsłuchiwanie wyrazów enterem lub spacją. Znajdź wszystkie pary wyrazów.
Interaktywna gra, polegająca na łączeniu wyrazów w pary w ciągu jednej minuty. Czas zaczyna upływać wraz z rozpoczęciem gry. Jeden ruch to odkrywanie najpierw jednej potem drugiej karty z wyrazem. Każdy wyraz jest odczytywany. Kolejny ruch to odkrywanie trzeciej i czwartej karty. W ten sposób odsłuchasz wszystkie wyrazy. Nawigacja z poziomu klawiatury za pomocą strzałek, odsłuchiwanie wyrazów enterem lub spacją. Znajdź wszystkie pary wyrazów.
Match Polish terms with their English equivalents.
voltage
acoustic wave
wahadło matematyczne
napięcie
okres drgań
speed of sound propagation
mathematical pendulum
vibration period
prędkość rozchodzenia się dźwięku
fala akustyczna
Source: GroMar, licencja: CC BY 3.0.
Glossary acoustic wave acoustic wave
fala akustyczna
RTllyafvQWFBO 1 wymowa w języku angielskim: acoustic wave
wymowa w języku angielskim: acoustic wave
Source: GroMar, licencja: CC BY 3.0.
frequency frequency
częstotliwość
R1OeLXJ595vdy 1 wymowa w języku angielskim: frequency
wymowa w języku angielskim: frequency
Source: GroMar, licencja: CC BY 3.0.
mathematical pendulum mathematical pendulum
wahadło matematyczne
R1DkE23mpLXCf wymowa w języku angielskim: mathematical pendulum
wymowa w języku angielskim: mathematical pendulum
Source: GroMar, licencja: CC BY 3.0.
power power
moc
R11YT5qSpN0BL 1 wymowa w języku angielskim: power
wymowa w języku angielskim: power
Source: GroMar, licencja: CC BY 3.0.
resistance resistance
siła oporu
R1JGUtQXcrbEH 1 wymowa w języku angielskim: resistance
wymowa w języku angielskim: resistance
Source: GroMar, licencja: CC BY 3.0.
second pendulum second pendulum
wahadło sekundowe
R1ZBH5VIcqiNF 1 wymowa w języku angielskim: second pendulum
wymowa w języku angielskim: second pendulum
Source: GroMar, licencja: CC BY 3.0.
speed of sound propagation speed of sound propagation
prędkość rozchodzenia się dźwięku
R2aRfVBXa0nlt wymowa w języku angielskim: speed of sound propagation
wymowa w języku angielskim: speed of sound propagation
Source: GroMar, licencja: CC BY 3.0.
vibration period vibration period
okres drgań
R1db0Ew7R9zce wymowa w języku angielskim: vibration period
wymowa w języku angielskim: vibration period
Source: GroMar, licencja: CC BY 3.0.
voltage voltage
napięcie
R1C9uuGdGCnMt 1 wymowa w języku angielskim: voltage
wymowa w języku angielskim: voltage
Source: GroMar, licencja: CC BY 3.0.
work work
praca
Rzs0nRrT8UnEj 1 wymowa w języku angielskim: work
wymowa w języku angielskim: work
Source: GroMar, licencja: CC BY 3.0.
Keywords acoustic wave acoustic wave acoustic wave
mathematical pendulum mathematical pendulum mathematical pendulum
speed of sound propagation speed of sound propagation speed of sound propagation
vibration period vibration period vibration period
voltage voltage voltage
